Toshiba B-SX5

High Performance Printing

Printing is fast with superb clarity due to an innovative print head with 306 DPI. The units are powered by a fast 32-bit processor with 8 MB DRAM and 4 MB Flash memory for programs and large file storage.

Dual platen rollers prevent media slipping or skewing and assist accurate forward or back-feeding.

Reliability and Maintenance

The design is a field-proven heavy-duty steel cabinet with a robust inner mechanism to ensure reliability. Access to the printhead, platen, paper path and sensors is quick and easy with the wide opening mechanism and clam-head providing easy maintenance.

Upgrade to the Future

The B-SX5 is a proven and reliable investment being designed with the future in mind with optional interfaces including LAN Ethernet. All units support email, XML and FTP protocols for remote printing and standardized data exchange.

RFID is a major new development in barcode label printing and the B-SX5 are loaded with the latest technology including SPRiNT direct tag inlay coding.

Model Differences

The B-SX4 has a maximum print width of 104 mm and uses 203 DPI resolution, whereas the B-SX5 has a maximum print width of 128 mm and is 306 DPI. The B-SX5 has a Ribbon Save Module and an Expansion I/O port as standard.

Technical Specification

Size and Weight

Height: 308 mm (12.1 inches)
Width: 291 mm (11.5 inches)
Depth: 460 mm (18.1 inches)
Weight: 20 kg (44.1 pounds)

Connections

Built-in:
Two Serial (RS-232C) ports internal & external
Parallel port
Expansion I/O port
Optional:
USB 1.1 port
Internal 10/100BASE Ethernet port
Two PCMCIA ports

Performance

Print resolution: 306 DPI — 12 dots per mm
Print width: up to 128 mm (5 inches)
Print length: Maximum of 1,498 mm
Print speeds:
3-inches per second (76.2 mm/s)
5-inches per second (127 mm/s)
8-inches per second (203.2 mm/s)
Media width: 30 to 140 mm (1.2–5.5 inches)

Fonts Embedded

21 Bitmap fonts
7 Outline fonts
132 Writable character fonts
20 TrueType fonts—optional

Barcode Symbology

1D linear barcodes supported

JAN-8
JAN-13
EAN-8
EAN-8+2 digits
EAN-8+5 digits
EAN-13
EAN-13+2 digits
EAN-13+5 digits
UPC-E
UPC-E+2 digits
UPC-E+5 digits
UPC-A
UPC-A+2 digits
UPC-A+5 digits
MSI
ITF
NW-7
CODE-39
CODE-93
CODE-128
EAN-128
Industrial 2 to 5
Customer Bar Code
POSTNET
KIX CODE
RM4SCC
RSS-14

2D barcodes supported

Data Matrix
PDF 417
Maxicode
QR code
Micro PDF 417
CP Code

RFID

Ultra High Frequency (UHF) tags:

EPC Class 1
ISO 18000-6B

High Frequency (HF) tags:

TAGSYS—C210, C220, C240
I-Code
Tag-It
ISO 15693

Electrical and Operating Requirements

Line voltage: 220–240 V AC
Frequency: 50 Hz ±10%
Power consumption: 0.7 A, 124 W (printing), 0.16 A, 16 W (standby)
Operating temperature: 5 to 40 °C (40 to 104 °F)
Relative humidity: 25–85% non-condensing

Warranty and Service

The Toshiba B-SX5 comes with a two-year limited warranty that includes up to 3 months onsite cover. Purchase a Toshiba Service Contract to extend service and support for up to five years of onsite cover. Only a Toshiba Service Contract provides you with onsite servicing from the Toshiba Service Engineer Network using genuine Toshiba parts. For more information visit Toshiba Service or call 01892 837722.

Accessories (sold separately)

B-SX5 without RFID

Expansion I/O Board (B-7704-IO-QM)
PCMCIA PC Board (B-7704-IO-QM)
Built-in LAN PC Board (B-9700-LAN-QM)
USB PC Board (B-9700-USB-QM)
Fanfold Paper Guide (B-4905-FF-QM)
Swing Cutter Module (B-4205-QM)
Rotary Cutter Module (B-8204-QM)
Strip Module (B-9904-H-QM)
Ribbon Save Module (B-9904-R-QM)
RFID UHF Module (B-9704-RFID-U1-EU)
RFID HF Module (B-9704-RFID-H1-QM)

B-SX5 with RFID

Expansion I/O Board (B-7704-IO-QM-R)
PCMCIA PC Board (B-7704-IO-QM-R)
Built-in LAN PC Board (B-9700-LAN-QM-R)
USB PC Board (B-9700-USB-QM-R)
Fanfold Paper Guide (B-4905-FF-QM-R)
Swing Cutter Module (B-4205-QM-R)
Rotary Cutter Module (B-8204-QM-R)
Strip Module (B-9904-H-QM-R)
Ribbon Save Module (B-9904-R-QM-R)
Cleaning Kit (CL-KITM02)
